Noise Barrier QCIT-NB-01

QCIT Noise Barrier Specification
Material:
1. Metal type: galvanized metal sheet, aluminum sheet.
     Appearance: shutter type, punching type.
    Colors: clear, lake blue, green, blue, opal, brown, silvery gray, red(Other color can be ordered according to you request
 2. Transparent sheet: PC, PMMA
Noise Barrier Size and Specification:
Noise Barrier panel thickness: 80mm, 100mm,120mm
Noise Barrier panel size: 2500x500x80mm, 2500x500x100mm, etc.
Noise Barrier metal plate thickness: 0.5-1.5mm
Noise Barrier H-post: 100x100x6x8mm, 125x125x6.5x9mm, 150x150x7x10mm, 175x175x7.5x11mm.
Noise Barrier H-post flange plate: 250x250x10, 300x300x10, 350x350x10, 400x400x10mm etc.



QCIT Sound noise barrier feature:
Effective noise barriers typically reduce noise levels by 5 to 10 decibels (dB), cutting the loudness
of traffic noise by as much as one half.
For example, a barrier which achieves a 10-15dB reduction can reduce the sound level of a typical
tractor trailer pass-by to that of an automobile.
